Art 26313

Accessories

Adaptable to

ISO fan nozzle
Series SF 110° - 08

ugello d.1,8 KEMATAL bianco (25PZ)

Disponibile nelle categorie : FAN AND CONE SPRAY NOZZLE

Description

If properly fitted onto the boom and at the right distance from the area to be sprayed, they ensure smooth coverage.
Made of molded acetal resin, a polymer ensuring high chemical stability and an exceptionally long useful life.
Suitable for herbicides, fungicides and pesticides.

Caratteristiche Tecniche

The table expresses the quantities of dispersed liquid (in liters per hectare), as a function of speed (in km/hour) and operating pressure.
The results were obtained using clean water and checking the pressure with a pressure gauge placed immediately before the nozzle.

Data

Minimum working pressure 1.5 Bar

Maximum working pressure 7 Bar

Flow rate 2.26 ÷ 4.89 l/min

Spray angle 110 °

Material Kematal

Color ISO White

net weight 0.001 kg

Accessories

Product	Date	Purchase
26065 Nozzle head with bayonet connection and seal	Disponibile nelle categorie : HEADS FOR WEEDING NOZZLES Colour Red Nozzle type SF - WRC - LDC - CFA - AFC - AOC - API - CVI - CVI TWIN - ATP net weight 0.01 kg
28026 Nozzle head with bayonet connection and seal	Disponibile nelle categorie : HEADS FOR WEEDING NOZZLES Colour Blue Nozzle type SF - WRC - LDC - CFA - AFC - AOC - API - CVI - CVI TWIN - ATP net weight 0.01 kg
28027 Nozzle head with bayonet connection and seal	Disponibile nelle categorie : HEADS FOR WEEDING NOZZLES Colour Green Nozzle type SF - WRC - LDC - CFA - AFC - AOC - API - CVI - CVI TWIN - ATP net weight 0.01 kg
28028 Nozzle head with bayonet connection and seal	Disponibile nelle categorie : HEADS FOR WEEDING NOZZLES Colour Yellow Nozzle type SF - WRC - LDC - CFA - AFC - AOC - API - CVI - CVI TWIN - ATP net weight 0.01 kg
28029 Nozzle head with bayonet connection and seal	Disponibile nelle categorie : HEADS FOR WEEDING NOZZLES Colour Brown Nozzle type SF - WRC - LDC - CFA - AFC - AOC - API - CVI - CVI TWIN - ATP net weight 0.01 kg
